A ntxiv rau Z Sereis Linear-tig Electric Actuator

A ntxiv rau Z series linear-tig hluav taws xob actuator

Lub linear-tig actuator outputs push-rub force thiab linear displacement. Feem ntau yog siv rau ib leeg thiab ob lub rooj regulating valve, lub tes tsho valve, rooj vag valve, thiab lwm yam.

Kev taw qhia luv luv

Cov cuab yeej linear-tig ua haujlwm nrog ntau hom ntau lub tshuab hluav taws xob los tsim cov kab hluav taws xob tig hluav taws xob rau ntau yam kev siv,

xws li ST6 plus VE50S, T14 plus VE200S. lwm.

Yog xav paub ntxiv, thov mus saib cov nplooj ntawv tom ntej. Hauv kev xaiv cov ntsuas rau hluav taws xob actuators, thov ua raws li cov qauv hauv qab no:

Actuator torque=khiav thrust x moment/thrust

Tag nrho-stroke cycles=Max. stroke x cycle/stroke

Lub sijhawm ua haujlwm=60x cycles/actuator ceev (rpm)

Diversity muaj nuj nqi

1. Kev tiv thaiv tshaj torque: Lub actuator muaj kev tiv thaiv kev tiv thaiv ntau dhau, uas tuaj yeem ntsuas qhov ua haujlwm ntawm lub valve kom raug. Thaum lub zog ua haujlwm siab tshaj qhov ntau, qhov hloov pauv ntawm lub zog dhau yuav ua, thiab kev tswj xyuas Circuit Court yuav tsum tsis txhob ua haujlwm ntawm cov kev taw qhia thiab tso tawm cov teeb liab. Thaum lub cev muaj zog nres, lub valve thiab lub actuator yuav raug tiv thaiv.

2. Lub cev muaj zog tiv thaiv overheat: muaj cov thermal relay hauv lub cev muaj zog, thiab lub cev muaj zog yuav txiav tawm lub hwj chim thaum lub cev muaj zog yog overheat.

3. Kev tiv thaiv hluav taws xob: Cov kev tawm tswv yim thiab cov khoom tawm yog txhua qhov kev sib cais ntawm optically.

4. txwv kev tiv thaiv: lub valve txoj hauj lwm yog kuaj los ntawm ib tug precision potentiometer, thiab plaub ntawm nws tus kheej adjustable cams yog ntsia rau ntawm lub mechanism los tswj lub sab sauv thiab qis txoj hauj lwm ntawm tus actuator.

5. Tawm teeb liab tiv thaiv: Lub regulating actuator muaj lub teeb liab kuaj xyuas Circuit Court. Yog tias qhov kev tawm tswv yim lossis cov zis raug txiav tawm, tus actuator tuaj yeem khaws nws qhov qub tsw thiab khiav mus rau qhov kaw tag nrho lossis qhib tag nrho txoj haujlwm xwm txheej ceev.

6. Kev tiv thaiv hluav taws xob tawm: SE actuator yog mechanically kaw nws tus kheej, thiab lub actuator nres nyob rau hauv qhov xwm txheej ntawm lub hwj chim tsis ua hauj lwm.

7. Tes: lub log ua haujlwm: Tsav lub log muab kev pabcuam thaum muaj xwm txheej ceev thaum muaj hluav taws xob tsis ua haujlwm lossis lub tshuab hluav taws xob tsis ua haujlwm.

8. Fais braking muaj nuj nqi: Lub modulating actuator muaj kev ua haujlwm ntawm hluav taws xob braking los tiv thaiv kev cuam tshuam ntawm lub valve thaum lub cev muaj zog inertia loj dhau thiab txhim kho kev tswj kom raug.

9. High torque qis inertia lub cev muaj zog: Ib-theem lossis peb-theem tag nrho cov squirrel-cage induction motors nrog siab pib torque, qis rotational inertia thiab me me pib tam sim no.

10. Qhov taw qhia txoj hauj lwm: Txoj hauj lwm qhia tias cov zis tam sim no yog 4 ~ 20mADC. Cov zis impedance Tsawg dua lossis sib npaug ntawm 75Ω, cov zis tam sim no tsis tu ncua.

Main techincal tsis

1. Cov teeb liab tso zis: 4 ~ 20mA Impedance 250Ω, tso zis teeb liab: 4 ~ 20mA Impedance Tsawg dua lossis sib npaug rau 750Ω

2. Qhov chaw tuag (rhiab heev): 0.3 ~ 3 feem pua ​​​​kho tsis tu ncua.

3. Qhov yuam kev yooj yim: - ntxiv rau 1 feem pua:- ntxiv rau 1.5 feem pua

4. Rov qab sib txawv: Tsawg dua lossis sib npaug - ntxiv rau 1 feem pua

5. Damping yam ntxwv: tsis muaj viav vias (Zero voj voog viav vias)

6. Fais fab mov: ib theem; 220V (230v) ~ - ntxiv rau 10 feem pua ​​​​50HZ

Peb-theem 380V (440V) ~ - ntxiv rau 10 feem pua ​​​​50HZ

7. Kev tiv thaiv qib: IP67

8. Ib puag ncig kub: -20 degree ~ 70 degree

9. Ib puag ncig cov av noo: Tsawg dua lossis sib npaug li 95 feem pua

10. Kev ua haujlwm zaus: 600 zaug hauv ib teev, 50 feem pua ​​​​ua haujlwm

Khoom nthuav qhia

Model specifications
